Products

Software packages



You can get our solution as pure software to integrate with your own hardware/product.
It runs on a x86 Intel hardware on top of standard Linux (Fedora, Ubuntu…) in user mode (no kernel patch required).

LTE 100

AMARI LTE 100


  • Full LTE network software suite
  • Includes EPC, eNB, eMBMSGW and IMS
  • Install and start end to end communication within 10 minutes

CONTACT US

For more details, check Software specification

LTE 100

AMARI LTE 100


  • The AMARI LTE 100 is a 100% software suite including eNB, EPC, eMBMS gateway and IMS test server.
  • It allows end to end communication from up to 1000 commercial UEs.
  • Our components are 3GPP release 13 compliant and are easy to install and configure through JSON config files.
  • The system is ready for automation and administration using our WebSocket remote API.
  • It is available as a standard license or as a floating license.

CONTACT US

For more details, check Software specification

LTE UE 100

AMARI UE 100


  • UE simulator software interacting with your base LTE station
  • Up to 1000 simulated UEs
  • Available in five versions: 1, 64, 128, 256 or an unlimited number of UEs
  • Supports two 20Mhz MIMO 2×2 cells

CONTACT US

For more details, check Software specification

LTE UE 100

AMARI UE 100


  • The AMARI UE 100 is a 100% software UE simulator.
  • Connected to your LTE network EPC/eNodeB with a radio frontend, you will simulate behavior of up to 1000 UEs stressing your network.
  • Each UE can be handled independently and perform LTE procedures and IP traffic simulation.
  • You can also use your own external application for dedicated protocol tests.
  • It is available as a standard license or as a floating license.

CONTACT US

For more details, check Software specification

OTS

You can get our solutions in a plug and play fully integrated PC.
It works directly out of the box!

LTE OTS10x

AMARI OTS 100


  • Full LTE network PC
  • Works out of the box
  • Any band (70Mhz to 6Ghz)
  • UE and SIM card included

CONTACT US

For more details, please check Software specification

LTE OTS10x

AMARI OTS 100


  • The AMARI OTS 100 system is a fully integrated PC working as a standalone LTE network.
  • It is provided with a standard UE and its 4G test SIM card to allow end to end communication directly out of the box.
  • It is available in 4 versions with 1 to 4 radio frontends to handle multi cell and carrier aggregation cases.
  • Any 3GPP LTE band is supported with any bandwidth.

CONTACT US

For more details, check Software specification

LTE OTS UE 10x

AMARI OTS UE 100


  • Pre-integrated UE simulator
  • Ready for LTE and IP simulations
  • Any band (70Mhz to 6Ghz)

CONTACT US

For more details, please check Software specification

LTE OTS UE 10x

AMARI OTS UE 100


  • The AMARI OTS UE 100 system is a fully integrated and configured PC running LTE UE 100 software.
  • It is available in 4 versions with 1 to 4 radio frontends.
  • Connect it using cables or antenna to your LTE base station (macro, femto…)
  • Create complex scenario and get results from our powerful log mechanism

CONTACT US

For more details, check Software specification

Radio frontend

To use with our software, here is a selection of available radio frontends.

SDR PCIe board

SDR PCIe board


  • All bands supported
  • MIMO 2×2
  • TDD and FDD
  • Multiple card chaining

CONTACT US

"SDR

SDR PCIe board


Features:

  • 2×2 RF transceiver (AD9361) with integrated 12-bits DACs and ADCs
  • RF coverage: 70 Mhz to 6.0 Ghz
  • RF bandwidth: 200kHz to 56Mhz
  • Supports TDD and FDD operation
  • PCIe 1x standard connector
  • Integrated GPS for precise time and frequency synchronization
  • Clock/PPS inputs and outputs for easy chaining
  • Documented C API for Linux/x86

Physical specifications:

  • RF power output <10 dBm
  • 4 SMA female (TX1, TX2, RX1, RX2)
  • 1 SMA female (GPS antenna with DC power supply)
  • 2 internal 5-pin connectors for inter-card time synchronization
  • DC power 12V @ 5W from PCIe connector
  • PCIe Full height – Short length
  • CE – ROHS

RRH

Third part radio frontends


Looking for a SDR radio frontend? Please consult our SDR partners.


Looking for a high power indoor/outdoor RRH? Please consult our RRH partners.
